JDL300 500m Water Well Drilling Rig Deep Hole Crawler Hydraulic Exploration Coring

Name: JDL300 500m Water Well Drilling Rig Deep Hole Crawler Hydraulic Exploration Coring
Brand: XDEM
Price: 30 USD

JDL300 500m Water Well Drilling Rig Deep Hole Crawler Hydraulic Exploration Coring Manufactures

Brand Name : XDEM

Model Number : JDL300

Place of Origin : Henan, China

MOQ : 1 set

Price : 30,000

Payment Terms : L/C, T/T

Supply Ability : 50 Set/Sets per Month

Delivery Time : 10 days

Condition : New

Warranty of core components : 1 Year

Drilling Depth : 500m

Max. Drilling Dia. (mm) : Φ350

Power model : pneumatic/mud drilling

Motor power : 42kw

Weight : 4380 KG

Drill rod diameter : Φ50/Φ76/Φ89/Φ102

Walking speed : 0~2 km/h

Rotational speed : 50~1020r/min

Contact Now

Product Description:

The JDL-300 water and air dual-purpose drilling rig is a mechanical top drive drilling equipment that integrates water drilling and air drilling. It effectively solves the problems of difficult air down-the-hole hammer drilling in soil layers and low construction efficiency of water drilling mud drilling in hard rock layers, gravel layers and pebble layers. The water and air dual-purpose drilling rig is suitable for various strata and is highly efficient and energy-saving in well drilling and core drilling in geological exploration.

Features:

1. The drilling rig can be equipped with a five-speed manual integrated transmission, hydraulic separation bearings, and full synchronizer gear shifting, which features high reliability and a long service life.

2. The drilling rig adopts a mechanical winch, which has a fast lifting speed and is convenient for handling accidents at the bottom of the well.

Parameters:

JDL300 500m Water Well Drilling Rig Deep Hole Crawler Hydraulic Exploration Coring
